Isolation/Type
Power Supply
Accuracy
Temp Coefficient
Linearity
Insulation Resistance
Input to output to power/Transformer isolation type
AC 95VA-250V(50~60Hz ±10%)
±0.1%(Max)
±0.015% / °C
±0.02% F.S
Greater than 100MΩ with DC 500V
Dielectric Strength Input - Power AC 2500V
Input - Output 1 minute
GND - Power AC 1000V
Overrange Output
Response Time
Operating Temperature/Humidity
Storage Temperature/Humidity
Dimensions
Case Material
Weight
Mounting
approx.-10% ~ 110% at DC 1~5V ±5%
≦0.5 sec (0~90%)
-20~60°C / 90%(N.C)
-20~80°C / 95%(N.C)
W34xH105xD100(mm)
ABS Resin (black or Gray)
about 200g
Din Rail mounting
