MODEL "TR" SERIES - STANDARD MODELS:

Tensitron TR meters can be equipped with different contact elements to easily measure tension in a wide variety of applications. TR units come standard with V-grooved pulleys for measuring wire and filaments. For special applications, such as thin tapes and webs, braided material, or tow, equip your meter with scooped, cylindrical, or flanged contact elements by ordering an “R” Custom Roller Option:

Model Number Range in Grams Accuracy*
TR-25 3 - 25 g

+/- 2 g

TR-125 3 - 125 g +/- 10 g
TR-250 3 - 250 g +/- 20 g
TR-1000 5 - 1000 g +/- 80 g
TR-2000 25 - 2000 g +/- 160 g
TR-4000 50 - 4000 g +/- 320 g
TR-5000 100 - 5000 g +/- 400 g

* Unless a "Special Calibration" is requested and a sample material is provided, the accuracy is +/-8% full-scale.

All Trigger Tension Meters have a dial face that use the black numbers in the first revolution of the pointer and red numbers in the second revolution.
