Measuring Principle

Glass electrode

Application

Water, waste water, process, galvanic

Characteristic

Resistent against electrolyte poisoning and dirt repellent gel-electrode including process connection NPT 3/4". Optional with amplifier.

Measurement range

pH 0-14

Measuring principle

Gel-compact electrode with double chamber reference system, kalium nitrate bridge electrolyte and PTFE-diaphragm.

Design

Compact electrode in PPS housing with NPT3/4" process connection.

Material

PPS / glass / PTFE

Dimension

Length: 120´mm
(4.68 inch)

Process temperature

-10°C - 110°C
(14°F - 230°F)

Process pressure

max. 10 bar
(145 psi)

Temperature sensor

Optional with integrated Pt100.
