Application
Function principle absolute
Revolution type singleturn
Electrical data
Operating voltage [V] 10...30 DC
Current consumption [mA] 100; ((24 V))
Reverse polarity protection yes
Outputs
Code binary
Measuring/setting range
Resolution 8192 steps; 13 bit
Software / programming
Parameter setting options counting direction of the code values; Resolution; Zero point; limit switches HI and LO; motion indicator; separation multiturn/singleturn
Diagnostic functions alarms; warnings; status; serial number of the encoder
Addressing address selector switch; 0...126
