Input
Isolation/Type
Power Supply
Accuracy
AC Voltage(PT)
Input to output to power/Transformer isolation type
AC rating ±10%, approx. 3.5VA
DC rating ±10%, (ripple 10%)100mA
±0.35%(Max

Temp Coefficient
Ripple
Linearity
±0.02%, / ℃(±0.008% / ℉)
0.5% p-p(Max)
±0.3% F.S

Insulation Resistance ±0.015%, /℃(±0.008% / ℉)
±0.02% F.S
Greater than 100MΩ with DC 500V

Dielectric Strength Input - Power
Input - Output AC 2500V
Output 1 - Output 2 1 minute
GND - Power AC 1000V
AC 2500V
AC 1000V
Front Adjustments
Overrange Output
Response Time
Operating Temperature/Humidity
Storage Temperature/Humidity
Zero and Span ±5%
approx.-10% ~ 110% at DC 1~5V
≦0.5 sec (0~90%)

Dimensions
Case Material
Weight
Mounting
a/-20~60°C / 90%(N.C)
-20~80°C / 95%(N.C)
