Isolation/Type Input to output to power / Transformer isolation type
Power Supply
Accuracy
AC rating ±10%, approx 4VA(Analog output at 7.5VA)
±0.15%(Max)

Temp Coefficient
Linearity
Insulation Resistance
±0.015%, /℃(±0.008% / ℉)
±0.02% F.S
Greater than 100MΩ with DC 500V

Dielectric Strength Input - Power
Input - Output
Output - Output
GND - Power
AC 2500V
AC 1000V
Front Adjustments
Overrange Output
Response Time
Operating Temperature/Humidity
Storage Temperature/Humidity
Zero and Span ±5%
approx - 10% ~ 110% at DC 1~5V
0.5 sec (0~90%)
-20~60℃ / 90%(N.C)
-20℃~80℃ / 95%(N.C)

Dimensions
Case Material
Weight
Mounting
W65×H129×D138(mm)
Aluminum(black)
about 1000g
Wall mounting
