Product Dimensions Shaft design Shaft diameter
RV3100 incremental Ø 58 / L = 79.5 mm solid shaft 10 mm
RB3500 incremental Ø 36.5 / L = 65 mm solid shaft 6 mm
RO3100 incremental Ø 58 / L = 69 mm hollow shaft open to one side 12 mm
RB3100 incremental Ø 36.5 / L = 65 mm solid shaft 6 mm
RV3500 incremental Ø 58 / L = 79.5 mm solid shaft 10 mm
RA3101 incremental Ø 36.5 / L = 58.5 mm hollow shaft open to one side 6 mm
RA3100 incremental Ø 36.5 / L = 58.5 mm hollow shaft open to one side 6 mm
RO3101 incremental Ø 58.5 / L = 69 mm hollow shaft open to one side 12 mm
RU3100 incremental Ø 58 / L = 63.5 mm solid shaft 6 mm
RO3500 incremental Ø 58.5 / L = 68.6 mm hollow shaft open to one side 12 mm
RO3501 incremental Ø 58.5 / L = 68.6 mm hollow shaft open to one side 12 mm
RU3500 incremental Ø 58 / L = 63.5 mm solid shaft 6 mm
RA3500 incremental Ø 36.5 / L = 58.5 mm hollow shaft open to one side 6 mm
RA3501 incremental Ø 36.5 / L = 58.5 mm hollow shaft open to one side 6 mm
RO3104 incremental Ø 58.5 / L = 69 mm hollow shaft open to one side 15.875 mm
RO3102 incremental Ø 58.5 / L = 69 mm hollow shaft open to one side 15 mm
RO3103 incremental Ø 58.5 / L = 69 mm hollow shaft open to one side 9.525 mm
RU3110 incremental Ø 58 / L = 63.5 mm solid shaft 6 mm
RO3110 incremental Ø 58.5 mm hollow shaft open to one side 15 mm
RA3103 incremental Ø 36.5 / L = 58.5 mm hollow shaft open to one side 10 mm
RV3110 incremental Ø 58 / L = 79.5 mm solid shaft 10 mm
