Product Dimensions Shaft design Shaft diameter
RM9000 absolute Ø 36.5 / L = 100 mm solid shaft 10 mm
RM9001 absolute Ø 36.5 / L = 100 mm solid shaft 10 mm
RM3011 absolute Ø 58 / L = 110 mm solid shaft 10 mm
RM8004 absolute Ø 36.5 / L = 74 mm hollow shaft open to one side 12 mm
RM3007 absolute Ø 58 / L = 110 mm solid shaft 10 mm
RM9010 absolute Ø 42 / L = 107.9 mm solid shaft 10 mm
RM8001 absolute Ø 36.5 / L = 69.5 mm solid shaft 6 mm
RM8002 absolute Ø 36.5 / L = 79 mm solid shaft 10 mm
RM8003 absolute Ø 36.5 / L = 67 mm hollow shaft open to one side 12 mm
RM3006 absolute Ø 58 / L = 94 mm solid shaft 6 mm
RM3008 absolute Ø 58.5 / L = 99 mm hollow shaft open to one side 12 mm
RM7011 absolute Ø 58 / L = 94 mm solid shaft 6 mm
RM7012 absolute Ø 58 / L = 110 mm solid shaft 10 mm
RN7012 absolute Ø 58 / L = 99 mm solid shaft 10 mm
RM7013 absolute Ø 58 / L = 110 mm solid shaft 10 mm
RN7011 absolute Ø 58 / L = 83 mm solid shaft 6 mm
RM9003 absolute Ø 36.5 / L = 100 mm solid shaft 10 mm
