Product Dimensions Shaft design Shaft diameter
RU3500 incremental Ø 58 / L = 63.5 mm solid shaft 6 mm
RM8002 absolute Ø 36.5 / L = 79 mm solid shaft 10 mm
RM8003 absolute Ø 36.5 / L = 67 mm hollow shaft open to one side 12 mm
RA3500 incremental Ø 36.5 / L = 58.5 mm hollow shaft open to one side 6 mm
RM3006 absolute Ø 58 / L = 94 mm solid shaft 6 mm
RM3008 absolute Ø 58.5 / L = 99 mm hollow shaft open to one side 12 mm
RN3001 absolute Ø 58 / L = 99 mm solid shaft 10 mm
RM7011 absolute Ø 58 / L = 94 mm solid shaft 6 mm
RM7012 absolute Ø 58 / L = 110 mm solid shaft 10 mm
RN7012 absolute Ø 58 / L = 99 mm solid shaft 10 mm
RM7013 absolute Ø 58 / L = 110 mm solid shaft 10 mm
RA3501 incremental Ø 36.5 / L = 58.5 mm hollow shaft open to one side 6 mm
RN7011 absolute Ø 58 / L = 83 mm solid shaft 6 mm
ROP523 incremental Ø 58.5 / L = 69 mm hollow shaft open to one side 9.525 mm
RO3104 incremental Ø 58.5 / L = 69 mm hollow shaft open to one side 15.875 mm
RO3102 incremental Ø 58.5 / L = 69 mm hollow shaft open to one side 15 mm
RO3103 incremental Ø 58.5 / L = 69 mm hollow shaft open to one side 9.525 mm
RU3110 incremental Ø 58 / L = 63.5 mm solid shaft 6 mm
RO3110 incremental Ø 58.5 mm hollow shaft open to one side 15 mm
RA3103 incremental Ø 36.5 / L = 58.5 mm hollow shaft open to one side 10 mm
RV3110 incremental Ø 58 / L = 79.5 mm solid shaft 10 mm
RM9003 absolute Ø 36.5 / L = 100 mm solid shaft 10 mm
