Power Supply DC 24V Type
AC 24V Type
AC Type
DC18V ~ 30V,(ripple 10%) 80mA
AC12V ~ 25V(50~60Hz), 3VA
AC95 ~ 250V / 50~60Hz
Display
Accuary
7Segment 4Digit
±0.1% Full Scale, ±1 Digit(25℃ ±5℃)

Input Impedance V Type
Pt100Ω, T/C Type
400㏀
1MΩ
Sampling cycle V Type
Pt100Ω, T/C Type
200ms
400ms
CMRR 140dB or More
NMRR 50dB or More
Sensor Power DC24V / 30mA (±5% or less)
Temp Coefficient
Isolation Resistance
±0.015% / ℃
Greater then 100MΩ with DC500V

Dielectric Sterngth Input - Power
Output - Power
GND - Power
AC2000V
AC1000V
Operating Temperature / Humidity
Storage Temperature / Humidity
Dimensions
Case Material
Weight
Mounting
a/-20~60℃ / 90% (N.C)
-20~80℃ / 95% (N.C)
W50 X H110 X D138(mm)
ABS Resin ( black)
about 980g
Wall mounting
